80X CHEETAH SCHEMATICS (BLACK, BRONZE) |
|
| P.code |
Name |
Label |
|
BARREL BLUED 80X CAL 9 SHORT (380 AUTO) |
01 |
| C45567 |
80X #40 - SAFETY PIN SPRING |
40 |
| C52177 |
80X #29 - EJECTOR |
29 |
| C52245 |
80X #5 - EXTRACTOR .380 (9 SHORT) |
05 |
| C53199 |
MAGAZINE CATCH |
451 |
| C54040 |
80X #28 - FIRING PIN LATCH LEVER SPRING |
28 |
| C54045 |
80X #30 - HAMMER INTERCEPTOR SPRING |
30 |
| C54069 |
80X #18 - TRIGGER SPRING |
18 |
| C54119 |
80X #24 - TRIGGER BAR SPRING |
24 |
| C54121 |
80X #21 - HOLD OPEN SPRING |
21 |
| C54172 |
80X #44 - SEAR SPRING |
44 |
| C55157 |
80X #37 - HAMMER PIN |
37 |
| C55967 |
80X #23 - TAKE DOWN LEVER BUTTON |
23 |
| C55968 |
MAGAZINE RELEASE BUTTON SPRING BUSH LEFT HAND LH |
49 |
| C55969 |
MAGAZINE RELEASE BUTTON SPRING BUSH RH RIGHT HAND |
47 |
| C56012 |
80X #33 - HAMMER SPRING GUIDE |
33 |
| C56756 |
GRIP BUSH 92 SERIES AND 80X |
52 |
| C57943 |
80X #31 - HAMMER INTERCEPTOR |
31 |
| C58673 |
80X #11 - FIRING PIN |
11 |
| C59851 |
80X #13 - FIRING PIN LATCH SPRING GUIDE |
13 |
| C5H455 |
80X #43 - SEAR |
43 |
| C5L269 |
80X #27 - FIRING PIN LATCH LEVER |
27 |
| C5L270 |
80X #22 - TAKE DOWN LEVER |
22 |
| C5L288 |
80X #10 - FIRING PIN SPRING |
10 |
| C5L289 |
80X #50 - HAMMER SPRING |
50 |
| C5L292 |
80X #7 - EXTRACTOR PIN |
07 |
| C5L293 |
80X #4 - FRONT SIGHT WHITE DOT |
04 |
| C5L310 |
80X #32 - BLUED SKELETONIZED HAMMER |
32 |
| C5L349 |
80X #19 - TRIGGER BAR |
19 |
| C5L451 |
80X #8 - RDO COVER WITH REAR SIGHT |
08 |
| C5L469 |
80X #51 - HAMMER CAP |
51 |
| C5L510 |
80X #17 - TRIGGER BLUED |
17 |
| C5L528 |
MIRINO TRIZIO MIRINO TRIZIO |
04 |
| C5M329 |
80X #36 - TRIGGER DISENGAGEMENT LEVER |
36 |
| C5M331 |
80X #35 - RIGHT SAFETY LEVER |
35 |
| C5M332 |
80X #38 - LEFT SAFETY LEVER |
38 |
| C5M333 |
80X #20 - HOLD OPEN |
20 |
| C5M342 |
80X #56 - RIGHT GRIP |
56 |
| C5M343 |
80X #55 - LEFT GRIP |
55 |
| C5N279 |
80X #5 - FIRING PIN LATCH |
15 |
| C86915 |
80X - MAG RELEASE BLUED |
58 |
| C8G672 |
80X #2 - RECOIL SPRING & ROD |
02 |
| C8J000 |
13 ROUNDS .380 MAGAZINE 80X |
57 |
| C8J001 |
10 ROUNDS .380 STANDARD MAGAZINE 80X |
57 |
| C8J003 |
15 ROUNDS .380 MAGAZINE 80X |
57 |
| C90051 |
80X #6 - EXTRACTOR SPRING |
06 |
| C90178 |
MAGAZINE CATCH SPRING 92 / 96 / 98 |
48 |
| C90356 |
80X #14 - FIRING PIN LATCH SPRING |
14 |
| C92111 |
SAFETY PLUNGER SPRING SERIE 81 SERIE 92X |
39 |
| C92211 |
80X #25 - HAMMER INTERCEPTOR PIN |
25 |
| C95066 |
GRIP BLUED SCREW FOR 92 SERIE AND 80X |
54 |
| C97065 |
ELASTIC WASHER 92 SERIES AND 80X |
53 |
| C97088 |
PIN 1,80X15 |
26 |
| C97088 |
PIN 1,80X15 |
42 |
| C97092 |
80X #45 - HAMMER SPRING CAP ELASTIC PIN |
45 |
| C97117 |
SPRING PIN (1.5X8MM) |
34 |
| C9A412 |
80X #41 - CYLINDRICAL PIN 2,5X24 |
41 |
| C9A413 |
80X #12 - SLIDE ELASTIC PIN |
12 |
| C9A551 |
80X #9 - RDO COVER SCREW (1x) |
09 |
